Mô tả
Thông số kỹ thuật
| Chíp xử lý | : |
Support for Intel® Xeon® E3-1200 v5/E3-1200 v6 processors/Intel® Core™ processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package * For Intel® Xeon® E3-1200 v6 / 7th Generation Intel® Core™ processors support need to update the latest BIOS. L3 cache varies with CPU
|
| Bộ nhớ Ram | : |
2 x DDR4 DIMM sockets supporting up to 32 GB of system memory, Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.Dual channel memory architecture, Support for DDR4 2400/2133 MHz memory modules, Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules, Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
|
| Loại Ram | : |
2 x DDR4 DIMM sockets supporting up to 32 GB of system memory, Support for DDR4 2400/2133 MHz memory modules
|
| Chipset | : |
Intel® C232 Chipset
|
| Khe cắm mở rộng | : |
1 x PCI Express x16 slot, running at x16 2 x PCI Express x1 slots
|
| Giao tiếp | : |
6 x USB 3.0/2.0 ports (4 ports on the back panel, 2 ports available through the internal USB header) 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
|
| Bộ nhớ | : |
2 x DDR4 DIMM sockets supporting up to 32 GB of system memory * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. Dual channel memory architecture Support for DDR4 2400/2133 MHz memory modules Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
|
| Cổng I/O phía sau | : |
1 x PS/2 keyboard port 1 x PS/2 mouse port 4 x USB 3.0/2.0 ports 2 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks (Line In, Line Out, Mic In)
|
| Cổng I/O ở trong | : |
1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 6 x SATA 6Gb/s connectors 1 x CPU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB 3.0/2.0 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header 1 x serial port header 1 x Clear CMOS jumper
|
| Kết nối mạng LAN | : |
Realtek® GbE LAN chip (10/100/1000 Mbit)
|
| Âm thanh | : |
Realtek® ALC887 codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver. Support for S/PDIF Out
|
| Kích thước | : |
Micro ATX Form Factor; 22.6cm x 17.4cm
|
| Bảo hành | : |
36 tháng
|
| Hãng sản xuất | : |
Gigabyte
|
