Mô tả
Thông số kỹ thuật
| Loại Ram | : |
DDR4 5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC) /3466(OC)/3333(OC)/3200/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory
|
| Chipset | : |
B560
|
| Cổng xuất hình | : |
1 x DisplayPort 1.4, 1 x HDMI™ 1.4
|
| Âm thanh | : |
ROG SupremeFX 7.1-Channel High Definition Audio CODEC S1220A – Impedance sense for front and rear headphone outputs – Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking – High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in) – Supports up to 32-Bit/192 kHz playback*” Audio Features – SupremeFX Shielding Technology – Savitech SV3H712 AMP – Rear audio USB Type-C® port – Premium Japanese audio capacitors – Audio cover
|
| Khe PCI | : |
Intel® 11th &10th Gen Processors 1 x PCIe 4.0/3.0 x16 slot(s) – Intel® 11th processors support PCIe 4.0 x16 mode – Intel®10th processors support PCIe 3.0 x16 mode Intel® B560 Chipset 1 x PCIe 3.0 x16 slot (supports x4 mode) 2 x PCIe 3.0 x1 slots
|
| Số cổng USB | : |
Rear USB: Total 9 ports 1 x USB 3.2 Gen 2×2 port(s) (1 x USB Type-C®) 1 x USB 3.2 Gen 2 port(s) (1 x Type-A) 7 x USB 2.0 port(s) (6 x Type-A, 1 x audio USB Type-C®) Front USB: Total 7 ports 1 x USB 3.2 Gen 2 connector(s) (suppport(s) USB Type-C®) 1 x USB 3.2 Gen 1 header(s) support(s) additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 ports
|
| Hệ điều hành hỗ trợ | : |
Windows® 10 64-bit
|
| Kích thước | : |
mATX Form Factor 9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )
|
| Bảo hành | : |
36 tháng
|
| Hãng sản xuất | : |
Asus
|
