Mô tả
Thông số kỹ thuật
| Chíp xử lý | : |
Build in Intel® Socket 1151 for 7th/6th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors Supports Intel® 14 nm CPU Supports Intel® Turbo Boost Technology 2.0
|
| Bộ nhớ Ram | : |
2 x DIMM, Max. 32GB, DDR4 2400/2133 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP)
|
| Card đồ họa | : |
Integrated Graphics Processor- Intel® HD Graphics support Multi-VGA output support : HDMI/RGB ports – Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz – Supports RGB with max. resolution 1920 x 1200 @ 60 Hz Maximum shared memory of 1024 MB Supports up to 2 displays simultaneously
|
| Loại Ram | : |
2 x DIMM, Max. 32GB, DDR4 2400/2133 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP)
|
| Chipset | : |
Build in Intel® H110
|
| Khe cắm mở rộng | : |
1 x PCIe 3.0/2.0 x16 (x16 mode, gray) 2 x PCIe 2.0 x1
|
| Giao tiếp | : |
Intel® H110 chipset : 4 x USB 3.1 Gen 1 port(s) (2 at back panel, blue, 2 at mid-board) Intel® H110 chipset : 6 x USB 2.0/1.1 port(s) (2 at back panel, black, 4 at mid-board)
|
| Cổng I/O phía sau | : |
1 x PS/2 keyboard (purple) 1 x PS/2 mouse (green) 1 x D-Sub 1 x HDMI 1 x LAN (RJ45) port(s) 2 x USB 2.0 1 x 8-channel Audio I/O 2 x USB 3.1 Gen 1 (blue)
|
| Cổng I/O ở trong | : |
1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (both SATA & x2 PCIE mode) 4 x SATA 6Gb/s connector(s) 1 x CPU Fan connector(s) (1 x 4 -pin) 1 x Chassis Fan connector(s) (1 x 4 -pin) 1 x 24-pin EATX Power connector(s) 1 x 4-pin ATX 12V Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x Clear CMOS jumper(s) 1 x 14-1 pin TPM connector 1 x System panel connector ,1 x Speaker connector
|
| Kết nối mạng LAN | : |
Realtek® RTL8111H, 1 x Gigabit LAN Controller(s) ASUS LAN Guard
|
| Âm thanh | : |
Realtek® ALC887 8-Channel High Definition Audio CODEC – Supports : Jack-detection, Front Panel Jack-retasking Audio Feature : – Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference – Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
|
| Kích thước | : |
Micro ATX Form Factor 8.3 inch x 6.85 inch ( 21.08 cm x 17.35 cm )
|
| Bảo hành | : |
36 tháng
|
| Hãng sản xuất | : |
ASUS
|
